Industrial USB Hub
A-423 10-Port USB 3.0 Hub
Model: Sipolar A-423
Confirm the input voltage range and supplied power adapter before ordering. Contact Sipolar.
A-423 10-Port USB 3.0 Hub | 10x USB-A 3.0 | Up to 5Gbps
- 10 x USB-A 3.0 for connected devices
- 1 x USB-B 3.0 host connection
- Up to 5Gbps data transfer performance
- Output details: 5 V / 2.1 A maximum per port
- over-current protection; short-circuit protection
Product Description
The Sipolar A-423 is a 10-port USB 3.0 hub for equipment integration and test benches. It provides 10 x USB-A 3.0 device connections and a 1 x USB-B 3.0 host connection. The specified USB data rate is up to 5 Gbps.
Technical Specifications
Product Information
| Model | Sipolar A-423 |
| Product Type | Industrial USB Hub |
| Product Name | A-423 10-Port USB 3.0 Hub |
| USB Specification | USB 3.0 |
| Downstream Port Count | 10 |
| Downstream Port Type | 10 x USB-A 3.0 |
| Upstream Port | 1 x USB-B 3.0 |
| Transfer Rate | Up to 5Gbps |
| LED Indicators | data connection indicator(green)/power indicator(red) |
Power & Electrical
| Power Interface | DC 5.5 x 2.1mm |
| Output Electrical Characteristics | 5V/2.1A(single-port maximum) |
| Charging Protocol | BC1.2,Apple,Samsung |
| Protection | over-current protection; short-circuit protection |
Physical
| Dimensions (L x W x H) | :190 x 80.6 x 23.94mm |
| Mechanical Structure | Housing: aluminum extrusion; Mounting: ear-mount |
| Cooling Method | Temperature-controlled cooling fan and ventilation openings |
| Net Weight | 300 g +/- 5 g |
Environmental
| Operating Temperature | -25°C to 80°C |
| Operating Humidity | RH 5% to RH 90% |
| Operating Altitude | 2 km or below |
Compatibility
| Supported OS | Windows XP, Windows 7, Windows 8, Windows 10, Windows 11; macOS 10.12 and above; Linux, Ubuntu 16.04 and above |
Package Contents
- A-423 product unit - 1
- USB 3.0 cable - 1
- User manual - 1
Contact us to confirm the supplied accessories for your order.
Frequently Asked Questions
What type of project is the A-423 designed for?
The A-423 is intended for professional USB, charging or power distribution projects where port count, power configuration and installation style need to be checked before ordering.
Can Sipolar support OEM or project requirements?
Contact Sipolar with port count, voltage, mounting and document requirements for project-specific confirmation.
Warranty
3-year limited warranty
