Industrial USB Hub
FD-603 16-Port USB 3.0 Hub
Model: Sipolar FD-603
Confirm the product version, power supply, per-port output and dimensions before ordering. Contact Sipolar.
FD-603 16-Port USB 3.0 Hub | 16x USB-A 3.0 | Up to 5Gbps
- 16 x USB-A 3.0 for connected devices
- 1 x USB-B 3.0 host connection
- Up to 5Gbps data transfer performance
- over-current protection; short-circuit protection
Product Description
The Sipolar FD-603 is a 16-port USB 3.0 hub for equipment integration and test benches. It provides 16 x USB-A 3.0 device connections and a 1 x USB-B 3.0 host connection. The specified USB data rate is up to 5 Gbps.
Technical Specifications
Product Information
| Model | Sipolar FD-603 |
| Product Type | Industrial USB Hub |
| Product Name | FD-603 16-Port USB 3.0 Hub |
| USB Specification | USB 3.0 |
| Downstream Port Count | 16 |
| Downstream Port Type | 16 x USB-A 3.0 |
| Upstream Port | 1 x USB-B 3.0 |
| Transfer Rate | Up to 5Gbps |
| LED Indicators | data connection indicator(green)/power indicator(red) |
Power & Electrical
| Power Interface | DC 5.5 x 2.1mm |
| Charging Protocol | BC1.2,Apple,Samsung |
| Protection | over-current protection; short-circuit protection |
Physical
| Mechanical Structure | Housing: aluminum extrusion+plastic; Mounting: ear-mount |
Environmental
| Operating Temperature | -25˜80°C |
| Operating Humidity | RH 5% to RH 90% |
| Operating Altitude | 2 km or below |
Compatibility
| Supported OS | Windows XP, Windows 7, Windows 8, Windows 10, Windows 11; macOS 10.12 and above; Linux, Ubuntu 16.04 and above |
| Driver Required | Windows installs the required USB hub driver automatically, as described in the user manual. |
Package Contents
- FD-603 product unit - 1
- USB data cable - 1
- User manual - 1
Contact us to confirm the supplied accessories for your order.
Frequently Asked Questions
What type of project is the FD-603 designed for?
The FD-603 is intended for professional USB, charging or power distribution projects where port count, power configuration and installation style need to be checked before ordering.
Can Sipolar support OEM or project requirements?
Contact Sipolar with port count, voltage, mounting and document requirements for project-specific confirmation.
Warranty
3-year limited warranty
