Industrial USB Hub
FS-803 10-Port USB-C 3.2 Hub
Model: Sipolar FS-803
Confirm the per-port output before ordering. Contact Sipolar.
FS-803 10-Port USB-C 3.2 Hub | 10x USB-A 3.0 | Up to 5Gbps | DC 9-24V(default power adapter12V x 4A)
- 10 x USB-A 3.0 for connected devices
- 1 x USB-C 3.1 host connection
- Up to 5Gbps data transfer performance
- DC 9-24V(default power adapter12V x 4A) input power details
- over-current protection; short-circuit protection
Product Description
The Sipolar FS-803 is a 10-port USB-C 3.2 hub for equipment integration and test benches. It provides 10 x USB-A 3.0 device connections and a 1 x USB-C 3.1 host connection. The specified USB data rate is up to 5 Gbps.
DC 9-24V(default power adapter12V x 4A) power details and Extruded aluminum housing; Desktop installation. Check enclosure dimensions, connector access and mounting clearances against your installation.
Technical Specifications
Product Information
| Model | Sipolar FS-803 |
| Product Type | Industrial USB Hub |
| Product Name | FS-803 10-Port USB-C 3.2 Hub |
| USB Specification | USB 3.2 |
| Downstream Port Count | 10 |
| Downstream Port Type | 10 x USB-A 3.0 |
| Upstream Port | 1 x USB-C 3.1 |
| Transfer Rate | Up to 5Gbps |
| LED Indicators | Blue device-connection indicator |
Power & Electrical
| Power Interface | DC 5.5 x 2.1mm |
| Input Electrical Characteristics | DC 9-24V(default power adapter12V x 4A) |
| Charging Protocol | BC1.2,Apple,Samsung |
| Protection | over-current protection; short-circuit protection |
Physical
| Dimensions (L x W x H) | :190 x 55 x 24 mm |
| Mechanical Structure | Housing: aluminum extrusion; Mounting: desktop |
Environmental
| Operating Temperature | -25°C to 80°C |
| Operating Humidity | RH 5% to RH 90% |
| Operating Altitude | 2 km or below |
Compatibility
| Supported OS | Windows XP, Windows 7, Windows 8, Windows 10, Windows 11; macOS 10.12 and above; Linux, Ubuntu 16.04 and above |
| Driver Required | Windows installs the required USB hub driver automatically, as described in the user manual. |
Package Contents
- FS-803 product unit - 1
- 12 V / 4 A power adapter - 1
- USB data cable - 1
- User manual - 1
Contact us to confirm the supplied accessories for your order.
Frequently Asked Questions
What type of project is the FS-803 designed for?
The FS-803 is intended for professional USB, charging or power distribution projects where port count, power configuration and installation style need to be checked before ordering.
Can Sipolar support OEM or project requirements?
Contact Sipolar with port count, voltage, mounting and document requirements for project-specific confirmation.
Warranty
3-year limited warranty
